Emergency Drench Shower Column - Stainless Steel
Description
Pedestal Mounted Emergency Drench Shower with stainless steel shower-head, stainless steel column, and a 1" stay-open ball valve with a quick pull rod.
Shower head: Stainless steel, 188 mm diameter showerhead with a 75 litres/minute flow regulator.
Valve: 1" rough stainless steel stay-open ball valve. Unit is provided with a stainless steel actuator arm and a 737 mm stainless steel pull rod.
Water Supply: 1-1/4" BSP female threaded stainless steel side or top inlet.
Piping & Mounting: Schedule 40 stainless steel piping and a 232 mm diameter stainless steel floor flange.
Universal Sign: ANSI compliant, vertical identification sign.
Weekly Test Tag: A water proof test card to record the date and inspector's name for weekly functional testing of the unit.
Compliances: Test rating conditions are compliant to ANSI Z358.1-2014
- Availability: Out Of Stock
- Code: S2300ASCS
